TH-40A400X
18
7.6. Chassis Frame
Fix screw follow the sequence procedure & right p/no.
No Description Qty UOM Remarks
001 SCREW (METAL10) 10 PC 5-7 Kgfcm
002 SCREW (BTM_METAL2) 2 PC 5-7 Kgfcm
