Panasonic TH-42PH11MK - AV Connection

SLOT3 SLOT2
PC IN
SLOT1
VIDEO
AUDIO
R L
AUDIO
R L
AV IN
S VIDEO
VIDEO
OUT
S VIDEO
OUT
AUDIO
OUT
R L
AUDIO
OUT
R L
B A
This unit has a terminal board equivalent to BNC Dual Video Terminal Board (TY-FB9BD) as standard equipment.
11
Connections
Note:
Additional equipment, cables and adapter plugs shown are not supplied with this set.
S VIDEO VCR
CAMCORDER
VCR
Example of input signal source
AV connection
