8.4.2 Quick adjustment after P.C.B. exchange
TOP PREVIOUS NEXT
*See the Panel label.
TOP PREVIOUS NEXT
P.C.B. Name Test Point Voltage Volume Remarks
P Board Vsus TPVSUS (SS) 170V ± 1V R605 (P)
Vda TPVDA (SS) 67V ± 1V R590 (P)
SC Board
Vbk TPVBK (SC) 155V ± 5V R6443 (SC)
Vad TPVAD (SC) -90V ± 1V R6477 (SC)
Vset TPVSET (SC) 218V ± 6V ---
Vscn TPVSCN (SC) Vad + 118 ± 2V ---
SS Board Ve TPVE (SS) 158V ± 1V R6774 (SS)
D, J Board
White blance, Pedestal and Sub brightness for NTSC, PAL, HD, PC and 625i signals
To Next Page
