Page #9 background imageLoading...
Page #9 background image
SCHEMA*99
8.3 Initialization Pulse Adjust
TOP PREVIOUS NEXT
1.Input a Cross hatch signal.
2.Set the picture controls: -
Picture mode: Normal
White balance: Cool
Adjust the indicated test point for the specified wave form.
TOP PREVIOUS NEXT
Test point Volume Level
T1
TPSC1 (SC)
R6523 (SC)
20 ± 15μ Sec
T2
TPSS1 (SS)
R6557 (SC)
170 ± 20μ Sec
