8.1.2 Adjustments
TOP PREVIOUS NEXT
Adjust and confirm indicated test point for the specified voltage.
Adjust
Confirm
TOP PREVIOUS NEXT
Name Volume Voltage Test Point Remarks
Vsus R605 170V ± 1V P11 pin 2
Vda R590 67V ± 0.5V
P12 pin 1
Name Voltage Test Point Remarks
15V 15.4V ± 0.5V P23 pin 1
15V 15.2V ± 0.5V P7 pin 1
12V 11.8V ± 0.5V P25 pin 1
Audio 12V 12.5V ± 0.8V P5 pin 7
5V 5.1V ± 0.3V
P25 pin 5
STB 5V 5.0V ± 0.3V
P27 pin 4
Fan 15V 15.4V ± 0.5V
P10 pin 1
Fan 5V 5.1V ± 0.3V
P10 pin 4
PFC 380V ± 15V
C468(+), C468(-)
