TH-49D400A/TH-49D400Z
13
7 Disassembly and Assembly Instructions
7.1. Key Button & LED Ass’y
1. Fix SP bracket.
2. Install SP unit.
3. Fix Key Button bracket.
4. Stick the barrier.
No Description Qty UOM Remarks
01 LED PANEL CASE 1 PC
02 LED PANEL 1 PC
03 SP BRACKET 4 PC
04 SPEAKER UNIT 2 PC
05 KEY BUTTON BRACKET 1 PC
06 BARRIER 1 PC
