TH-49D400A/TH-49D400Z
15
7.3. AV Bracket & Bottom Metal Ass’y
1. Stick felt to side AV bracket.
2. Fix Bottom Metal L and Bottom Metal R.
3. Fix Bottom Corner Cover L and Bottom Corner Cover R.
No Description Qty UOM Remarks
01 BOTTOM METAL L 1 PC
02 BOTTOM METAL R 1 PC
03 BOTTOM CORNER COVER L 1 PC
04 BOTTOM CORNER COVER R 1 PC
05 CHASSIS BRACKET A-PCB 1 PC
06 SIDE AV BRACKET 1 PC
07 FELT (W10 × L130 × T0.35) 1 PC
08 FELT (W10 × L50 × T0.55) 1 PC
09 FELT (W10 × L35 × T0.35) 1 PC
To Next Page
