TH-49D400A/TH-49D400Z
7
4 Specifications
Note
• Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.
Power
Rating AC 220-240 V, 50/60 Hz 0.55 A
Normal (Home) mode 98 W
Standby power consumption 0.20 W
Display panel
Panel LCD panel (LED backlight)
Visible screen size (diagonal) 123 cm
Display resolution 1,920 (W) × 1,080 (H)
Dimensions (W × H × D) 1,106 mm × 704 mm × 259 mm (With Pedestal)
1,106 mm × 644 mm × 80 mm (TV only)
Mass
14.0 (With Pedestal)
13.0 (TV only)
Connection terminals
AV IN (COMPONENT / VIDEO) VIDEO RCA PIN Type × 1, 1.0 V[p-p] (75 Ω)
AUDIO L - R RCA PIN Type × 2, 0.5 V [rms]
Y 1.0 V [p-p] (including synchronisation)
P
B
/ C
B,
P
R
/ C
R
±0.35 V [p-p]
HDMI 1 / 2 input TYPE A Connectors
USB USB 2.0 TYPE A Connectors
DC 5 V, Max. 500 A
DIGITAL AUDIO OUT PCM / Dolby Digital / Fibre optic
Sound
Audio output 20 W (10 W + 10 W)
Receiving Systems / Band name
Digital TV 7 MHz UHF (Australia) free-to-air TV broadcast reception
8 MHz UHF (New Zealand) free-to-air TV broadcast reception
PAL B / G Reception of Off air broadcasts
PAL 60 Hz Playback of NTSC tape from some PAL Video recorders (VCR)
M.NTSC Playback from M.NTSC Video recorders (VCR)
NTSC Playback from NTSC Video recorders (VCR)
Aerial input Standard Belling & Lee connector (Australia)
VHF / UHF (New Zealand)
Operating Conditions Temperature : 0°C - 35°C
Humidity : 20 % - 80 % RH (non-condensing)
