Model No. : TH-49D400A / TH-49D400Z Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
D7800 B0FCAM000004 DIODE
D7801 B0ECKM000053 DIODE
D7802 B0BC01500025 DIODE
D7803 B0ECKM000053 DIODE
D7804 DZ2J360M0L DIODE
D7805 B0ACCD000008 DIODE
D7806 B0BC01500025 DIODE
D7807 B0FCAM000004 DIODE
D7808 DA2J10100L DIODE
D7809 DA2J10100L DIODE
D7810 B0ACCD000008 DIODE
D7811 DZ2J360M0L DIODE
D7812 DA2J10100L DIODE
D7813 B0FCAM000004 DIODE
D7814 B0FCAM000004 DIODE
D8001 B0JCED000012 DIODE
D8002 B0JCED000012 DIODE
F7101 K5E502YYA213 FUSE
GK4 K1KY03BA0402 CONNECTOR
IC4300 C0DBAYY02430 IC
IC4900 C1AB00003984 IC
IC5602 C0DBZYY00723 IC
IC5704 C0DBEYY00102 IC
IC6750 C1AB00004172 IC
IC6751 C1AB00004174 IC TH-49D400A only (Australia)
IC7201 C0DBBYY00058 IC
IC7301 C0DBAYY01329 IC
IC7401 C0DBZYY00545 IC
IC7503 C0DBAYY01915 IC
IC7800 C0ZBZ0002179 IC
IC8001 C1AB00004199 IC TH-49D400Z only (N. Zealand)
IC8001 C1AB00004200 IC TH-49D400A only (Australia)
IC8002 C0DBAYY02437 IC
IC8003 C0DBAYY02430 IC
IC8004 C0DBAYY02430 IC
IC8005 C0DBAYY02430 IC
IC8008 C0DBGYY00887 IC
IC8900A TVR4G334-AA ROM VERSION ASSY TH-49D400A only (Australia)
IC8900A TVR4G336-AB ROM VERSION ASSEMBLY TH-49D400Z only (N. Zealand)
IC8901 TVR4G337-AB ROM VERSION ASSEMBLY TH-49D400Z only (N. Zealand)
IC8902 C3EBJY000066 IC
JA1 D0GDR00J0004 M 0 OHM, J, 1/8W
JA10 D0GFR00J0005 M 0 OHM, J, 1/3W
JA11 D0GFR00J0005 M 0 OHM, J, 1/3W
JA13 D0GFR00J0005 M 0 OHM, J, 1/3W
JA14 D0GFR00J0005 M 0 OHM, J, 1/3W
JA16 D0GFR00J0005 M 0 OHM, J, 1/3W
JA17 D0GFR00J0005 M 0 OHM, J, 1/3W
JA2 D0GDR00J0004 M 0 OHM, J, 1/8W
JA3 D0GDR00J0004 M 0 OHM, J, 1/8W
JA4 D0GDR00J0004 M 0 OHM, J, 1/8W
JA5 D0GDR00J0004 M 0 OHM, J, 1/8W
JK3101 K1U511D00002 AV TERMINAL
JK4700 K1FY119D0029 TERMINAL
JK4701 K1FY119D0029 TERMINAL
JK6752 K1ZZ00001557 TUNER SHIELD
JK7101 K2AAYB000010 AC INLET
JK8450 K1FY104B0092 TERMINAL
JS0037 D0GAR00JA039 M 0 OHM, 1/16W TH-49D400A only (Australia)
JS0044 D0GAR00JA039 M 0 OHM, 1/16W TH-49D400Z only (N. Zealand)
JS0066 D0GAR00JA039 M 0 OHM, 1/16W TH-49D400A only (Australia)
JS0072 D0GAR00JA039 M 0 OHM, 1/16W TH-49D400Z only (N. Zealand)
