TH-50FS600D
23
8 Measurements and Adjustments
8.1. Voltage chart of A-board
Set A-Board to a dummy set and check the satisfaction with the specified voltage as following table.
8.2. Voltage chart of P-board
Set P-Board to a dummy load and check the satisfaction with the specified voltage as following table.
Power Supply Name Measurement Point Specification (V)
PNL12V TP4103 11.3V - 13V
SUB5V TP5420 4.98V - 5.25V
SUB3.3V TP5400 3.14V - 3.46V
SUB1.8V TP5300 1.71V - 1.89V
HDMI3.3V TP8000 3.14V - 3.46V
PHY3.3V TP8002 3.14V - 3.46V
SUB1.2V TP8103 1.15V - 1.26V
SUB1.5V TP8101 1.45V - 1.57V
TU_1.8V TP5704 1.71V - 1.89V
Output Test Point GND Step 1 Step 2
PFC TP7201/02 TP7203/04 < 340V 390V ± 15V *HOT
5VS TP7405/20 TP7427/31/32 5.25 ± 0.2V 5.25 ± 0.2V
16V TP7410/11/12 TP7427/31/32 < 1V 16 ± 0.6V
64V TP7408/09 TP7427/31/32 < 1V 68V ± 10V
