10 Wiring Connection Diagram
10.1. Wire Dressing
No Description Qty UOM
01 LVDS CABLE 1 PC
02 PET TAPE 0.96 MT
03 WIRE (LDP1-PANEL) 1 PC
04 WIRE (A02-P2/LDP) 1 PC
05 WIRE (A11-K10) 1 PC
06 WIRE (A12-SP) 1 PC
07 WIRE (P5-GK) 1 PC
08 WIFI DONGLE WIRE 1 PC
09 AL TAPE 1 PC
