Panasonic TH-50PX6U

1 Difference PCB Structure sheet 4
1.1. TH-42PX6U
4
1.2. TH-50PX6U
4
2 Service Hint
5
2.1. TH-42PX6U
5
2.2. TH-50PX6U
6
3 Plasma panel replacement method
7
3.1. Remove the S-Board
7
3.2. Remove the K-Board
7
4 Location of Lead Wiring
8
4.1. Lead of Wiring (1)
8
4.2. Lead of Wiring (2)
9
5 Conductor Views
11
5.1. H-Board
11
5.2. K and S-Board
13
5.3. DG-Board
14
5.4. DT-Board
16
6 Schematic and Block Diagram
19
6.1. Schematic Diagram Note
19
6.2. Main Block Diagram (42inch)
20
6.3. Main Block Diagram (50inch)
21
6.4. H-Board Block Diagram
22
6.5. H-Board (1 of 3) Schematic Diagram
23
6.6. H-Board (2 of 3) Schematic Diagram
24
6.7. H-Board (3 of 3) Schematic Diagram
25
6.8. K and S-Board Block and Schematic Diagram
26
6.9. DG-Board (1 of 3) Block Diagram
27
6.10. DG-Board (2 of 3) Block Diagram
28
6.11. DG-Board (3 of 3) Block Diagram
29
6.12. DG-Board (1 of 8) Schematic Diagram
30
Channel Capability
(Digital/Analog)
VHF/UHF: 2 - 69,
CATV: 1 - 135
Operating Conditions Temperature : 0°C-40°C
Humidity : 20 % - 80 % RH (non-condensing)
Connection Terminals
INPUT 1-2 VIDEO: RCA PIN Type × 1 1.0 V[p-p] (75 W)
S-VIDEO: Mini DIN 4-pin Y: 1.0 V[p-p] (75 W) C: 0.286 V[p-p] (75 W)
AUDIO L-R: RCA PIN Type × 2 0.5 V[rms]
COMPONENT VIDEO
INPUT 1-2
Y: 1.0 V[p-p] (including synchronization)
P
B
,P
R
:±0.35 V[p-p]
AUDIO L-R: RCA PIN Type × 2 0.5 V[rms]
HDMI 1-2 TYPE A Connector1.0 V[p-p] (including synchronization)
AUDIO L-R: RCA PIN Type × 2 0.5 V[rms]
Card slot
(SERVICE ONLY)
SD CARD slot × 1
AV PROG. OUT VIDEO: RCA PIN Type × 1 1.0 V[p-p] (75 W)
AUDIO L-R: RCA PIN Type × 2 0.5 V[rms]
DIGITAL AUDIO OUT PCM/ Dolby Digital, Fiver Optic
FEATURES 3D Y/C FILTER
Dimensions ( W × H × D )
Including pedestal 42.1” × 30.1” × 12.6” (1,068 mm × 764 mm × 320 mm) (TH-42PX6U)
49.5” × 34.6” × 14.6” (1,257 mm × 877 mm × 370 mm) (TH-50PX6U)
TV Set only 42.1” × 27.6” × 3.8” (1,068 mm × 701 mm × 97 mm) (TH-42PX6U)
49.5” × 32.1” × 3.8” (1,257 mm × 814 mm × 97 mm) (TH-50PX6U)
Weight
Including pedestal 70.5 lb. (32 kg) (TH-42PX6U) 97.0 lb. (44 kg) (TH-50PX6U)
TV Set only 66.1 lb. (30 kg) (TH-42PX6U) 90.4 lb. (41 kg) (TH-50PX6U)
Notes:
·
· ·
· Design and Specifications are subject to change without notice. Weight and Dimensions shown are approximate.
