TH-L32X50D
14
7 Disassembly and Assembly Instructions
7.1. SP Bracket
1. Fix Sp. Bracket to LCD panel with screw (Fig. A).
2. Fix Speaker Unit (L&R) to Sp. Bracket (Fig. B).
No Item Description Qty
043 TKX5ZA02301 SP BRACKET 4
058 XYN3+F8FJ SCREW 4
059 L0EYAA000006 SPEAKER UNIT L 1
060 L0EYAA000007 SPEAKER UNIT R 1
To Next Page
