TH-L32X50D
18
7.4. Barrier LCD
1. Fix LVDS Cable to bottom LCD panel (Fig. A).
2. Stick LVDS cable & A10~K10 wire with pet tape (Fig. A).
3. Stick barrier LCD to LCD Panel (Fig. B).
No Parent Item Description Qty
063 TK3M TSCKF0010005 LVDS CABLE 1
068 TK3M T4FP1505J PET TAPE 0.1
087 TK3M TMK4GX087 BARRIER LCD 1
To Next Page
