TH-L32X50D
7
4 Specifications
Power Source AC 110 - 240 V, 50 / 60 Hz
Power Consumption
Power Rating 60 W
Standby Condition 0.25 W
Display panel
Panel system LED LCD panel
Visible screen size (diagonal) 82 cm / 32 inches
Number of pixels 1,049,088 (1,366 (W) × 768 (H))
Dimensions (W × H × D) 761 mm × 517 mm × 230 mm (With Pedestal)
761 mm × 463 mm × 53 mm (TV only)
Mass 10.0 kg Net (With Pedestal)
8.0 kg Net (TV only)
Sound
Speaker (75 mm × 22 mm) × 2, 8 Ω
Audio Output 20 W (10 W + 10 W)
Headphones M3 (3.5 mm) stereo mini Jack × 1
Receiving Systems / Band name 17 SYSTEMS FUNCTIONS
1 PAL B, G, H
Reception of broadcast transmission and
playback from video cassette tape
recorders.
2 PAL I
3 PAL D, K
4 SECAM B, G
5 SECAM D, K
6 SECAM K1
7 NTSC M (NTSC 3.58 / 4.5MHz)
8 NTSC 4.43 / 5.5 MHz
Playback from special VCR’s or DVD.
9 NTSC 4.43 / 6.0 MHz
10 NTSC 4.43 / 6.5 MHz
11 NTSC 3.58 / 5.5 MHz
12 NTSC 3.58 / 6.0 MHz
13 NTSC 3.58 / 6.5 MHz
14 SECAM I
15 PAL 60 Hz / 5.5 MHz Playback from Special Disc Players and
Special VCR’s or DVD.
16 PAL 60 Hz / 6.0 MHz
17 PAL 60 Hz / 6.5 MHz
Receiving Channels (Analogue TV)
VHF BAND 2 - 12 (PAL / SECAM B, K1)
0 - 12 (PAL B AUST.)
1 - 9 (PAL B N.Z.)
1 - 12 (PAL / SECAM D)
1 - 12 (NTSC M JAPAN)
2 - 13 (NTSC M USA)
UHF BAND 21 - 69 (PAL G, H, I / SECAM G, K, K1)
28 - 69 (PAL B AUST.)
13 - 57 (PAL D, K)
13 - 62 (NTSC M JAPAN)
14 - 69 (NTSC M USA)
CATV
S1 - S20 (OSCAR)
1 - 125 (
USA CATV)
C13 - C49 (JAPAN)
S21 - S41 (HYPER)
Z1 - Z37 (CHINA)
5A, 9A (AUST.)
Aerial - Rear VHF / UHF
Operating Conditions Temperature : 0°C - 40°C
Humidity : 20 % - 80 % RH (non-condensing)
Connection Terminals
AV1 IN AUDIO L-R RCA PIN Type × 2 0.5 V [rms]
VIDEO RCA PIN Type × 1 1.0 V [p-p] (75 Ω)
AUDIO OUTPUT AUDIO L-R RCA PIN Type × 2 0.5 V [rms] (high impedance)
AV2 IN AUDIO L-R RCA PIN Type × 2 0.5 V [rms]
COMPONENT Y 1.0 V[p-p] (including synchronisation)
P
B
/C
B
, P
R
/C
R
±0.35 V[p-p]
VIDEO RCA PIN Type × 1 1.0 V [p-p] (75 Ω)
