TH-L42E6S
16
7.2. Rear Panel Assembly
1. Fix rear panel “L” [Rear & Bottom] and “R” [Rear] ass’y at LCD Panel.
2. After fix rear panel Top & Bottom assembly at LCD Panel.
No. Item Description QTY UOM Ref. Type
01 TXFKP5Z0102 REAR PANEL TOP ASSY 1 PC Fig. 3
02 TXFKP5Z0115 REAR PANEL L ASSY 1 PC Fig.1
03 TXFKP5Z0129 REAR PANEL R ASSY 1 PC Fig. 2
04 TXFKP5Z0194 REAR PANEL BTM ASSY 1 PC Fig. 4
To Next Page
