TH-L42E6S
24
7.10. Back Cover Assembly 2
Fixing Screw for Back cover.
No. Item Description QTY UOM Remarks
01 N5HBZ0000101 WIFI MODULE 1 PC
02 THEC1509 SCREW(BC22/WIFI1/HDMI3) 26 PC Refer to spec.
03 XTV3+8GFJK SCREW(BC3/AV1) 4 PC Refer to spec.
04 THTD030J SCREW(BC3) 3 PC 10 ± 2 Kgfcm
To Next Page
