Model No. : TH-L42E6S Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
R8905 D0GA222JA023 C 2.2KOHM ,J, 1/16W
R8906 D0GA472JA023 M 4.7KOHM, J,1/16W
R8910 D0GA103JA039 M 10KOHM,F,1/16W
R8913 D0GA472JA023 M 4.7KOHM, J,1/16W
R8914 D0GA472JA023 M 4.7KOHM, J,1/16W
R8915 D0GA472JA023 M 4.7KOHM, J,1/16W
R8942 D0GA473JA039 M 47KOHM J. 1/10W
R8943 D0GA473JA039 M 47KOHM J. 1/10W
R8944 D0GA101JA039 M 100OHM ,J, 1/10W
R9005 D0GA153JA023 C 15KOHM ,J, 1/16W
R9006 D0GA472JA023 M 4.7KOHM, J,1/16W
TRANSFORMERS
T7201 G4DYA0000443 TRANSFORMER
T7301 G4DYA0000448 TRANSFORMER
OTHERS
A02 K1KY14BA0484 CONNECTOR
A10 K1KY07BA0483 CONNECTOR
A12 K1KY04BA0387 CONNECTOR
A16 K1MY51BA0526 CONNECTOR
A20 K1FY105E0017 CONNECTOR
CF7101 D4CAY4R7A096 THERMISTOR RESISTOR
CF7102 D4CAY4R7A096 THERMISTOR RESISTOR
CN0100 K1KA14A00248 CONNECTOR
F7101 K5E502YYA162 FUSE
GK4 K1KY03BA0402 CONNECTOR
JA1 D0GDR00J0004 CHIP RESISTOR
JA2 D0GDR00J0004 CHIP RESISTOR
JA3 D0GDR00J0004 CHIP RESISTOR
JA5 D0GDR00J0004 CHIP RESISTOR
JA51 D0GFR00J0005 CHIP RESISTOR
JK3101A K1U510D00002 TERMINAL
JK4701 K1FY119D0028 HDMI TERMINAL
JK4702 K1FY119D0028 HDMI TERMINAL
JK4703 K1FY119D0028 HDMI TERMINAL
JK6750 K1ZZ00001551 TUNER SHIELD
JK7101 K2AAYB000010 AC INLET
JK8601 K1FY104B0093 USB TERMINAL
JK8602 K1FY104B0093 USB TERMINAL
JK8650A K2LC1YYA0020 LAN TERMINAL
JS0048 D0GAR00J0005 CHIP RESISTOR
JS0066 D0GAR00J0005 CHIP RESISTOR
JS7406 D0GDR00J0004 CHIP RESISTOR
K10 K1KY07AA1311 CONNECTOR
LF7103 G0B183G00006 LINE FILTER
LF7104 G0B183G00006 LINE FILTER
LF7105 G0B350HA0036 LINE FILTER
P2 K1KY14BA0386 CONNECTOR
P4 K1KY08BA0402 CONNECTOR
P5 K1KY03BA0402 CONNECTOR
PA7401 ERBRE5R00V FUSE RESISTOR
PA7402 ERBRE5R00V FUSE RESISTOR
PA7406 ERBRE5R00V FUSE RESISTOR
PC7301 B3PAA0000629 PHOTO COUPLER
PC7302 B3PAA0000629 PHOTO COUPLER
PC7303 B3PAA0000629 PHOTO COUPLER
RM2800 B3RBB0000018 PHOTO DETECTOR
SN2800 B3JB00000208 IC
SW2851 EVQ11G05R SWITCH
SW2852 EVQ11G05R SWITCH
SW2853 EVQ11G05R SWITCH
SW2854 EVQ11G05R SWITCH
SW2855 EVQ11G05R SWITCH
