Panasonic TX-32PB50 - Page 36

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
CARBON R559 ERD25TJ273 0.25W 5% 27K
CARBONR560 ERD25TJ183 0.25W 5% 18K
CARBONR581 ERDS2TJ104T 2W 5% 100K
CARBONR582 ERD25TJ124 0.25W 5% 120K
CARBONR583 ERD25TJ103 0.25W 5% 10K
METAL R586 ERQ2CJP2R2 2W 5% 2R2
METALR591 ERO25TKF9311 0,25W 1% 9K31
S.M.CARBR1458 ERJ6ENF6801 0.1W 1% 6K8
S.M.CARBR1459 ERJ6ENF5491V 0.5W 5% 490
CAPACITORS
FILMC473 ECQV1H104J 50V
100nF
CERAMICC474 ECJ2VF1H103Z 50V
10nF
CERAMIC C521 ECKC3A152J 1KV
1500pF
CERAMICC522 ECKC3A272J 1KV
2.7µF
CERAMICC523 ECKC3A151J 1KV
150pF
FILMC524 ECQM6223JZW 600V
22nF
FILMC525 ECQM4223JZW 400V
22nF
CERAMICC526 ECKC3D101J 2KV
100pF
ELECT C527 ECA1HM010GB 50V
1µF
CERAMIC C528 ECKC3D471JB 2KV
470pF
ELECT C529 ECA1HM100GB 50V
10µF
CERAMICC530 ECKC3A681J 1KV
680pF
CERAMIC C531 ECKC3D102J 2KV
1nF
CERAMIC C554 ECKC3D681J 2KV
680pF
FILMC558 ECWH20472JVB 200V
4.7nF
FILMC559 ECQF4123JZH 400V
12nF
FILMC561 ECWH20512JVB 200V
5.1nF
FILMC562 ECQM4223KC 400V
220nF
FILMC577 ECWF2274JBB 200V
270nF
FILMC578 ECWF4304JBP 400V
300nF
FILMC579 ECWF4334JBB 400V
330nF
FILMC580 ECWF4474JBB 400V
470nF
FILMC583 ECQB1H223K 50V
22nF
CERAMICC1500 EEVHB0J101P 10V
100pF
CERAMICC2360 ECJ2VB1H223K 50V
22nF
CERAMICC2392 ECJ2VB1H223K 50V
22nF
CERAMICC2596 ECJ2YB1H333K 50V
33nF
CERAMICC2597 ECJ2YB1H333K 50V
33nF
TERMINALS AND LINKS
CRT SOCKET JK351 TJS1A5330
DIFFERENCES FOR MODEL TX--36PB50
EXPLODED VIEW
A P.C.B. 19 TNPH0348BP
ANODE CABLE 20 ZTBZAD650E
BACK COVER 21 TKU8E00700
C.R.T. 22 W86LPX955X07
CABINET 23 TKY8E580
CONTROL BRACKET 24 TMW8E049-1
D P.C.B. 25 TNPH0349
DEGAUSS COIL 26 TLK8E05147
DF P.C.B. 27 TNPA1806
FBT 28 ZTFM77009A
FOCUS LEAD ASSEMBLY 29 TXJF0C0EFG
G P.C.B. 30 TNP8EG004AB
L P.C.B. 31 TNPA1726AE
MODEL LABEL 32 TQF8E3203-1
PANASONIC BADGE 33 TBMA059
MISCELLANEOUS COMPONENTS
PRESET LABELRIGHT. TBM8E2138
LID SWITCH . TEK6935
SPEAKER PANEL LEFT. TKP8E1437
SPEAKER PANEL RIGHT. TKP8E1442
BOTTOM PANEL LEFT. TKP8E1446
BOTTOM PANEL RIGHT. TKP8E1456-1
TOP CARTON . TPC8E4908
BOTTOM CARTON . TPC8E4909
CARTON HANDLE . TPD169487
BOTTOM CUSHION . TPD8E764
SUB CUSHION . TPD8E778
SERVICE PACK . TZS1EK002
VIDEO CABINET . VS-36PBL
DEGAUSS RESISTOR R537 ERC12GK104V
CRT EARTH SPRING SK401 TES2298
CRT EARTH SPRING SK402 TES2298
SPEAKER (WOOFER) SPK1 EAB12149C2
SPEAKER (WOOFER) SPK2 EAB12149C2
SPEAKER (TWEETER) SPK3 EASG7DH08B2
SPEAKER (TWEETER) SPK4 EASG7DH08B2
CRT EARTH SPRING TES01 TES2298
CRT EARTH SPRING TES02 TES2298
INSTRUCTION BOOKS
OPERATING INSTRUCTIONS TQB8E3511
I.C.s
VERTICAL OUTPUT IC451 LA7876N
EAROM * IC1104 X24BR200-2IA
2.5V REGULATOR IC1252 PQ30RV21B
VIDEO PROCESSOR IC1301 C1AB00001468
VIDEO PROCESSOR IC1304 C1AB00001230
2.5V REGULATOR IC2402 PQ30RV21B
DIODES
DIODE D450 EU02AV1
DIODE D521 AU02AV0
DIODE D522 AU02AV0
DIODE D523 MA165TA5
DIODE D524 MA165TA5
DIODE D525 RP1HLFA5
DIODE D526 RP1HLFA5
TRANSISTORS
TRANSISTOR Q463 BC847B
TRANSISTOR Q521 2SK1006RF122
TRANSISTOR Q522 2SC3311ATA
TRANSISTOR Q523 2SC3311ATA
TRANSISTOR Q524 2SC5460LB
TRANSISTOR Q525 2SC3311ATA
TRANSFORMERS
TRANSFORMER T701 ETF18L101A
COILS
LINEARITY COIL L574 ELH5L7701
COIL L575 ELHKLB071B
COIL L576 ELC18B331E
COIL L702 ELC18B331E
RESISTORS
S.M.CARBJSZ7 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR353 ERJ6ENF1331 0.1W 1% 330
S.M.CARBR363 ERJ6ENF1331 0.1W 1% 330
S.M.CARBR372 ERJ6ENF1331 0.1W 1% 330
CARBONR451 ERDS1TJ3R3 0.5W 5% 3R3
CARBONR452 ERDS1TJ3R3 0.5W 5% 3R3
S.M.CARBR473 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR474 ERJ6GEYJ103 0.1W 5% 10K
METALR509 ERX3FJ1R0 3W 5% 1
CARBONR520 ERD25TJ153 0.25W 5% 15K
METALR521 ERG2FJS123 2W 5% 12K
CARBONR522 ERD25TJ101 0.25W 5% 100
CARBONR523 ERD25TJ103 0.25W 5% 10K
CARBONR524 ERD25TJ103 0.25W 5% 10K
CARBONR525 ERD25TJ102 0.25W 5% 1K
36
