DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M. CAPC3440 ECUV1H561KBX 50V 560pF
S.M. CAPC3441 ECUV1H561KBX 50V 560pF
S.M. CAPC3442 ECUV1H561KBX 50V 560pF
S.M. CAPC3443 ECUV1H561KBX 50V 560pF
CERAMICC3444 ECJ2VC1H102K 50V 1nF
CERAMICC3445 ECJ2VF1C105Z 16V 1pF
CERAMICC3446 ECJ2VF1C105Z 16V 1pF
S.M. CAPC3450 ECUV1H561KBX 50V 560pF
S.M. CAPC3460 ECUV1H104KBX 50V 100nF
ELECT C3461 ECA1HM101GB 50V 100µF
S.M. CAPC3462 ECUV1H104KBX 50V 100nF
S.M. CAPC3463 ECUV1H104KBX 50V 100nF
CERAMICC3465 TACCN0J105KT 6.3V 1µF
CERAMICC3480 TACCN0J105KT 6.3V 1µF
CERAMICC3481 TACCN0J105KT 6.3V 1µF
S.M. CAPC3483 ECUV1H104KBX 50V 100nF
CERAMICC3484 TACCN0J105KT 6.3V 1µF
ELECT C3487 ECEA1CN100 16V 10µF
ELECT C3489 ECEA1CN100 16V 10µF
CERAMICC3804 ECJ2VC1H180J 50V 18pF
CERAMICC3805 ECJ2VC1H180J 50V 18pF
CERAMICC3806 ECJ2VC1H180J 50V 18pF
CERAMICC3813 ECJ2YB1H104K 50V 100nF
CERAMICC3814 ECJ2YB1H104K 50V 100nF
CERAMICC3815 ECJ2YB1H104K 50V 100nF
ELECTC3816 ECA0JM221GB 6.3V 220pF
FILMC3817 F2A1E470A211 25V 47µF
FILMC3818 F2A1E470A211 25V 47µF
CERAMICC3819 ECJ2YB1H104K 50V 100nF
CERAMICC3820 ECJ2YB1H104K 50V 100nF
CERAMICC3821 ECJ2YB1H104K 50V 100nF
FILMC3822 F2A2E470A040 250V 47µF
FILMC3823 ECQM2104KZ 250V 100nF
FILMC3824 F2A2E470A040 250V 47µF
FILMC3828 ECQM2104KZ 250V 100nF
FILMC3833 F2A2E470A040 250V 47µF
CERAMICC3835 ECUV1H103JCN 50V 10nF
CERAMICC3836 ECUV1H103JCN 50V 10nF
CERAMICC3837 ECUV1H103JCN 50V 10nF
CERAMICC3838 ECKC3D332J 2KV 3.3µF
FILMC3839 ECQM2104KZ 250V 100nF
CERAMICC3841 ECJ2VF1C105Z 16V 1pF
CERAMICC4801 ECUV1H103JCN 50V 10nF
ELECT C4802 ECA1VM470B 35V 47µF
FILMC4803 ECQV1H334JL3 50V 330nF
FILMC4805 ECQB1H104J 50V 100nF
FILMC4806 ECQB1H104J 50V 100nF
ELECT C4808 ECA1VM470B 35V 47µF
ELECT C4815 ECA1VM470B 35V 47µF
S.M. CAPC4817 ECUV1H151JCX 50V 150pF
TERMINALS AND LINKS
AUDIO/VIDEO OUTPUT JACKJK3102 TJBA093
SCART SOCKET JK3401 0350536400
SCART SOCKET JK3402 0350536400
SCART SOCKET JK3403 0350536400
SCART SOCKET JK3405 0350536400
RCA TERMINAL (2P) JK3406 TJB8E014
PIN JACK JK3407 TJB8E036
SWITCHES
SWITCH S791 K0D123A00060
SWITCH S840 ESB92S11B
FUNCTION SWITCH S1003 EVQPC105K
FUNCTION SWITCH S1004 EVQPC105K
FUNCTION SWITCH S1005 EVQPC105K
FUNCTION SWITCH S1006 EVQPC105K
FUNCTION SWITCH S1007 EVQPC105K
RELAYS
RELAY RL801 K6B1ADA00010
RELAY RL802 K6B2ADA00004
DIFFERENCES FOR MODEL TX--32PD30D
EXPLODED VIEW
A P.C.B. 17 TNPH0525AF
ANODE CABLE 18 ZTBZAD550A
BACKCOVER 19 TKUC13902
C.R.T. (FINE PITCH) 20 W76LXK085X01
CABINET 21 TKYA21102
CHASSIS FRAME 22 TMX8E071
D P.C.B. 23 TNPH0526AC
DEGAUSS COIL 24 TLK8E05194
DF P.C.B. 25 TNPA3005AD
MODEL LABEL 26 TQF8E3448
MISCELLANEOUS COMPONENTS
CRT EARTH SPRING . TES2298
SP PANEL R . TKPA68002
SP PANEL L . TKPA68102
SIDE DECORATION R. TKPA68603
SIDE DECORATION L. TKPA68703
UNDER DECORATION R. TKPA69306
UNDER DECORATION L. TKPA69406
GEOMAGNETIC COIL . TLK8E05193
CARTON . TPC8E5003-1
TOP CUSHION . TPD8E802
BOTTOM CUSHION . TPD8E803
SUB CUSHION . TPD8E804
INSTRUCTION BOOKS
GERMAN TQB8E3936A
ITALIAN TQB8E3936C
FRENCH TQB8E3936D
I.C.s
EAROM* IC1007 X24BR200-3BD
DIODES
DIODE D521 B0HAKR000004
DIODE D522 B0HAKR000004
RESISTORS
METALR533 ERG3FJS681D 3W 5% 680 Ω
METALR587 ERO25CKF2202 0.25W 1% 22K Ω
CAPACITORS
FILMC851 ECQB1104JF3 100V 100nF
S.M. CAPC2713 ECUV1H104KBX 50V 100nF
DIFFERENCES FOR MODEL TX--32PD30F
EXPLODED VIEW
A P.C.B. 17 TNPH0525AH
ANODE CABLE 18 ZTBZAD550A
BACKCOVER 19 TKUC13902
C.R.T. (FINE PITCH) 20 W76LXK085X01
CABINET 21 TKYA21102
CHASSIS FRAME 22 TMX8E071
D P.C.B. 23 TNPH0526AC
DEGAUSS COIL 24 TLK8E05194
DF P.C.B. 25 TNPA3005AD
MODEL LABEL 26 TQF8E3461
MISCELLANEOUS COMPONENTS
CRT EARTH SPRING . TES2298
SP PANEL R . TKPA68002
