DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
SP PANEL L . TKPA68102
SIDE DECORATION R. TKPA68603
SIDE DECORATION L. TKPA68703
UNDER DECORATION R. TKPA69306
UNDER DECORATION L. TKPA69406
GEOMAGNETIC COIL . TLK8E05193
CARTON . TPC8E5003-1
TOP CUSHION . TPD8E802
BOTTOM CUSHION . TPD8E803
SUB CUSHION . TPD8E804
INSTRUCTION BOOKS
GERMAN/SPANISH TQB8E3981AE
DUTCH/FRENCH TQB8E3981BD
SWEDISH/NORWEGIAN TQB8E3981FG
FINNISH(SUOMI)/DANISH TQB8E3981HK
I.C.s
EAROM * IC1007 X24BR200-2BF
DIODES
DIODE D521 B0HAKR000004
DIODE D522 B0HAKR000004
RESISTORS
METALR533 ERG3FJS681D 3W 5% 680 Ω
METALR587 ERO25CKF2202 0.25W 1% 22K Ω
CAPACITORS
FILMC851 ECQB1104JF3 100V 100nF
S.M. CAPC2713 ECUV1H104KBX 50V 100nF
DIFFERENCES FOR MODEL TX--32PD30FP
EXPLODED VIEW
A P.C.B. 17 TNPH0525AJ
ANODE CABLE 18 ZTBZAD550A
BACKCOVER 19 TKUC13902
C.R.T. (FINE PITCH) 20 W76LXK085X01
CABINET 21 TKYA21102
CHASSIS FRAME 22 TMX8E071
D P.C.B. 23 TNPH0526AC
DEGAUSS COIL 24 TLK8E05194
DF P.C.B. 25 TNPA3005AD
MODEL LABEL 26 TQF8E3462
MISCELLANEOUS COMPONENTS
CRT EARTH SPRING . TES2298
SP PANEL R . TKPA68002
SP PANEL L . TKPA68102
SIDE DECORATION R. TKPA68603
SIDE DECORATION L. TKPA68703
UNDER DECORATION R. TKPA69306
UNDER DECORATION L. TKPA69406
GEOMAGNETIC COIL . TLK8E05193
CARTON . TPC8E5003-1
TOP CUSHION . TPD8E802
BOTTOM CUSHION . TPD8E803
SUB CUSHION . TPD8E804
INSTRUCTION BOOKS
BULGARIAN/ROMANIAN TQB8E3983MN
POLISH/HUNGARIAN TQB8E3983PQ
CZECH/ENGLISH TQB8E3983RU
I.C.s
EAROM* IC1007 X24C1400-2BP
DIODES
DIODE D521 B0HAKR000004
DIODE D522 B0HAKR000004
RESISTORS
METALR533 ERG3FJS681D 3W 5% 680 Ω
METALR587 ERO25CKF2202 0.25W 1% 22K Ω
CAPACITORS
FILMC851 ECQB1104JF3 100V 100nF
S.M. CAPC2713 ECUV1H104KBX 50V 100nF
DIFFERENCES FOR MODEL TX--36PD30D
EXPLODED VIEW
A P.C.B. 17 TNPH0525AB
ANODE CABLE 18 ZTBZAD650E
BACKCOVER 19 TKUC13802
C.R.T. (FINE PITCH) 20 W86LXK085X01
CABINET 21 TKYA21002
CHASSIS FRAME 22 TMX8E050
D P.C.B. 23 TNPH0526AB
DEGAUSS COIL 24 TLK8E05192
DF P.C.B. 25 TNPA3005AB
MODEL LABEL 26 TQF8E3439
MISCELLANEOUS COMPONENTS
FRONT PANEL . TKEA07002
SP PANEL L . TKPA67702
SP PANEL R . TKPA67802
SIDE DECORATION . TKPA68403
SIDE DECORATION . TKPA68503
UNDER DECORATION . TKPA69305
UNDER DECORATION . TKPA69405
GEOMAGNETIC COIL . TLK8E05191
CARTON . TPC8E5002
TOP CUSHION . TPD8E799
BOTTOM CUSHION . TPD8E800
SUB CUSHION . TPD8E801
SP PANEL L ASSEMBLY. TTPA0298
INSTRUCTION BOOKS
GERMAN TQB8E3927A
ITALIAN TQB8E3927C
FRENCH TQB8E3927D
I.C.s
EAROM* IC1007 X24C1400-2AD
DIODES
DIODE D521 AU02AV0
DIODE D522 AU02AV0
RESISTORS
METALR533 ERG3FJS821 3W 5% 820 Ω
METALR587 ERO25CKF1502 0.25W 1% 15K Ω
CAPACITORS
FILMC851 ECQE2154JF3 200V 150nF
S.M. CAPC2713 ECUV1H104KBX 50V 100nF
DIFFERENCES FOR MODEL TX--36PD30F
EXPLODED VIEW
A P.C.B. 17 TNPH0525AD
ANODE CABLE 18 ZTBZAD650E
BACKCOVER 19 TKUC13802
C.R.T. (FINE PITCH) 20 W86LXK085X01
CABINET 21 TKYA21002
CHASSIS FRAME 22 TMX8E050
D P.C.B. 23 TNPH0526AB
DEGAUSS COIL 24 TLK8E05192
DF P.C.B. 25 TNPA3005AB
