Panasonic TX-32PD30D - Page 38

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
MODEL LABEL 26 TQF8E3464
MISCELLANEOUS COMPONENTS
FRONT PANEL . TKEA07002
SP PANEL L . TKPA67702
SP PANEL R . TKPA67802
SIDE DECORATION . TKPA68403
SIDE DECORATION . TKPA68503
UNDER DECORATION . TKPA69305
UNDER DECORATION . TKPA69405
GEOMAGNETIC COIL . TLK8E05191
CARTON . TPC8E5002
TOP CUSHION . TPD8E799
BOTTOM CUSHION . TPD8E800
SUB CUSHION . TPD8E801
SP PANEL L ASSEMBLY. TTPA0298
INSTRUCTION BOOKS
GERMAN/SPANISH TQB8E3987AE
DUTCH/FRENCH TQB8E3987BD
SWEDISH/NORWEGIAN TQB8E3987FG
FINNISH(SUOMI)/DANISH TQB8E3987HK
I.C.s
EAROM* IC1007 X24C1400-2AF
DIODES
DIODE D521 AU02AV0
DIODE D522 AU02AV0
RESISTORS
METALR533 ERG3FJS821 3W 5% 820 Ω
METALR587 ERO25CKF1502 0.25W 1% 15K Ω
CAPACITORS
FILMC851 ECQE2154JF3 200V 150nF
S.M. CAPC2713 ECUV1H104KBX 50V 100nF
DIFFERENCES FOR MODEL TX--36PD30FP
EXPLODED VIEW
A P.C.B. 17 TNPH0525AE
ANODE CABLE 18 ZTBZAD650E
BACKCOVER 19 TKUC13802
C.R.T. (FINE PITCH) 20 W86LXK085X01
CABINET 21 TKYA21002
CHASSIS FRAME 22 TMX8E050
D P.C.B. 23 TNPH0526AB
DEGAUSS COIL 24 TLK8E05192
DF P.C.B. 25 TNPA3005AB
MODEL LABEL 26 TQF8E3463
MISCELLANEOUS COMPONENTS
FRONT PANEL . TKEA07002
SP PANEL L . TKPA67702
SP PANEL R . TKPA67802
SIDE DECORATION . TKPA68403
SIDE DECORATION . TKPA68503
UNDER DECORATION . TKPA69305
UNDER DECORATION . TKPA69405
GEOMAGNETIC COIL . TLK8E05191
CARTON . TPC8E5002
TOP CUSHION . TPD8E799
BOTTOM CUSHION . TPD8E800
SUB CUSHION . TPD8E801
SP PANEL L ASSEMBLY. TTPA0298
INSTRUCTION BOOKS
BULGARIAN/ROMANIAN TQB8E3985MN
POLISH/HUNGARIAN TQB8E3985PQ
CZECH/ENGLISH TQB8E3985RU
I.C.s
EAROM* IC1007 X24C1400-1AP
DIODES
DIODE D521 AU02AV0
DIODE D522 AU02AV0
RESISTORS
METALR533 ERG3FJS821 3W 5% 820 Ω
METALR587 ERO25CKF1502 0.25W 1% 15K Ω
CAPACITORS
FILMC851 ECQE2154JF3 200V 150nF
38
