7.1.3. Check Point
Confirm the following parts if NG was displayed.
7.1.4. Exit
Disconnect the AC cord from wall outlet or press the [POWER] button on the main unit for 3 seconds to turn off and then turn on
automatically.
DISPLAY Check Ref. No. Description Check Point
H14TUN TU6705 TUNER A-BOARD
H90STBY IC8000 PEAKS-LD6 (STM) A-BOARD
H92MEM1 IC8000 BLOCK-EEP A-BOARD
H91MEM2 IC8901 STM EEPROM A-BOARD
H17LAN IC8650 ETHERPHY A-BOARD
H00FE IC6800 DEMOD A-BOARD
H96ID ID A-BOARD
H97ID2 ID2 A-BOARD
H45BT BLUETOOTH A-BOARD/BLUETOOTH
H42WiFi WiFi A-BOARD/WiFi
