7
4 Specifications
Product fiche
TV
Energy efficiency class A+
Visible screen size (diagonal) 121 cm / 48 inches
On mode average power consumption (B/E) 63 W
Annual energy consumption
*1
(B/E)
88 kWh
Rated power consumption (R) 106 W
On mode power consumption / screen area (R)
0.010 W / cm
2
Standby power consumption
*2
0.20 W
Off mode power consumption 0.20 W
Screen resolution 1 920 (W) 1 080 (H)
*1: Energy consumption XYZ kWh per year, based on the power consumption of the television operating 4 hours per day for 365 days.
The actual energy consumption will depend on how the television is used.
*2: when the TV is turned off with the remote control and no function is active.
For the information of rated power consumption, refer to the label on the TV back cover.
Dimensions (W × H × D)
1 087 mm 676 mm 260 mm (With Pedestal) (B/E)
1 087 mm 632 mm 57 mm (TV only) (B/E)
1 087 mm 677 mm 214 mm (With Pedestal) (R)
1 087 mm 632 mm 57 mm (TV only) (R)
Mass
15.0 kg Net (With Pedestal)
14.0 kg Net (TV only)
Power source AC 220-240 V, 50 / 60 Hz
Panel LED LCD panel
Sound
Speaker output 20 W (10 W + 10 W)
Headphones M3 (3.5 mm) stereo mini Jack 1
Connection terminals
AV1 input / output
SCART (Audio/Video in, Audio/Video out, RGB in)
AV2 input (COMPONENT / VIDEO)
VIDEO RCA PIN Type 1 1.0 V [p-p] (75 )
AUDIO L - R RCA PIN Type 2 0.5 V [rms]
Y 1.0 V [p-p] (including synchronisation)
P
B
/C
B
, P
R
/C
R
± 0.35 V [p-p]
HDMI 1 / 2 / 3 input TYPE A Connectors
HDMI 1 / 3 : 3D, Content Type
HDMI 2 : 3D, Content Type, Audio Return Channel
• This TV supports "HDAVI control 5" function.
Card slot Common Interface slot (complies with CI Plus) 1
ETHERNET RJ45, IEEE802.3 10BASE-T / 100BASE-TX
USB 1 / 2
USB1 / 2: DC 5 V, Max. 500 mA [Hi-Speed USB (USB 2.0)]
DIGITAL AUDIO output PCM / Dolby Digital / DTS, Fibre optic
Receiving systems / Band name (B)
Check the latest information on the available services at the following website.
http://panasonic.net/viera/support
DVB-T / T2 Digital terrestrial services
(UK)
PAL I UHF E21 - 68
(Ireland)
PAL I VHF A - J
CATV S1 - S20
UHF E21 - E69
CATV S21 - S41 (Hyperband)
PAL 525/60 Playback of NTSC tape from some PAL Video recorders (VCR) or NTSC disc playback from
DVD player and recorder
M.NTSC Playback from M.NTSC Video recorders (VCR)
NTSC (AV input only) Playback from NTSC Video recorders (VCR)
