Panasonic TX-48AS640B - Disassembly Procedure for the Unit

22
8.2. Disassembly Procedure for the Unit
Lay down the unit so that the rear cover faces upward.
8.2.1. Pedestal
1. Remove the 4 screws.
2. Remove the Pedestal.
8.2.2. Back Cover
1. Remove the 19 screws (A).
2. Remove the 8 screws (B).
3. Remove the Back Cover.
8.2.3. P-Board
1. Remove the 7 screws.
2. Disconnect the connectors (P2, P4 and P5).
3. Remove the P-Board.
4. Remove the P-Board Barrier.
