Panasonic TX-L42D25B - Replacement Parts List; Important Safety Notice; RTL (Retention Time Limited)

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type number to your order.
Replacement Parts List
Important Safety Notice
The marking (RTL) indicates that the Retention Time is Limited for this item. After the
discontinuation of this assembly in production, the item will continue to be available for
a specific period of time. The retention period of availability is dependent on the type of
assembly, and in accordance with the laws governing part and product retention. After
the end of this period, the assembly will no longer be available.
RTL (Retention Time Limited)
Note:
X
The marking (X) indicates that board should be exchanged for service.
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
SPEAKER UNIT_L 1 EAB1428AL
SPEAKER UNIT_R 2 EAB1428AR
TUNER DVB-T/C 3 ENGF7801KF
TUNER DVB-T2 4 ENV57S03D8F
TUNER DVB-S 5 J3BBCBC00006
CONTROL PANEL ASSY 6 K0RB00600013
AC CORD 7 K2CT2YY00045
LCD PANEL 8 L5EDDAT00004
POWER UNIT 9 N0AE4JJ00006
REMOTE CONTROL 10 N2QAYB000504
PEDESTAL ASSY FIX 11 TBLX0167
CI SLOT COVER SHEET 12 TBM0E2226
CONNECTOR COVER 13 TKP0E16001
SIDE AV BRACKET 14 TKP0E44201
METAL SUPPORT SIDE 15 TKZ0EC5026
METAL SUPPORT CORNER 16 TKZ0EC5027
SUPPORT BOTTOM SIDE 17 TKZ0EC5028
METAL SUPPORT TOP 18 TKZ0EC5029
XW_XS HOLDER 19 TKZ0EC5031
METAL BRACKET BOTTOM 20 TKZC5163
STAND METAL BRACKET 21 TKZX5255
AC CORD BRACKET 22 TMW0E909
XW P.C.B. 23 TNPA5130BC
V P.C.B. 24 TNPA5134AA
TC P.C.B. 25 TNPA5195BD
BACK COVER ASSY 26 TTU0E0678
METAL SIDE AV BRACKET 27 TUW0E107
MISCELLANEOUS COMPONENTS
BATTERY . R6DB/2P
REAR AV LABEL . TBM0E2064
2ND TUNER LABEL . TBM0E2217
LED PANEL . TKKC5398
BARRIER_P UNIT . TMKY924
BARRIER_T-CON . TMKY928
BARRIER_A P.C.B. . TMKY969
BARRIER_A SHIELD . TMKY970
SPACER . TMM23416
CLAMPER . TMME268
CLAMPER . TMME355
CLAMPER . TMME385
PROTECTION SHEET . TPE0E4043
POLYBAG_PEDESTAL . TPE0E9004
STAND ACCESSORY ASSY. TXFBL010QDB
SCREW . XSS5+15FN
SCREW . XTV3+6JFJ
SCREW . XTW3+10TFJ
SCREW . XYN3+F6FJ
SCREW .XYN3+J8FJ
SCREW . XYN4+F12FJ
SCREW . XYN4+F6FJ
BOTTOM CUSHION BOTCUS1 TPD0E2111
BOTTOM CUSHION_CENTERBOTCUS2 TPD0E2114
CARTON CARTON TPC0EA02601
THERMAL PAD FA01 TMKK395
THERMAL PAD FA02 TMKK394
THERMAL PAD FA03 TMKK394
TOP CUSHION TOPCUS1 TPD0E1115
TOP CUSHION_CENTERTOPCUS2 TPD0E1120
I.C.s
MICRO_GENX IC1100 MNZSFH9GP91
EEPROM GENX IC1101 24LA02GENX
AUDIO AMPLIFIER IC2301 C1AB00003230
REGULATOR IC2950 C0CBCAG00031
REGULATOR IC2952 C0DBGYY00281
AUDIO VIDEO SWITCHIC3000 C1AB00003218
HDMI SWITCH IC4700 C1AB00003079
REGULATOR IC4701 C0DBGYY00578
ANALOG ASIC IC5000 AN34042A-VF
REGULATOR IC5200 C0DBEYY00124
REGULATOR IC5220 C0DBGYY00895
REGULATOR IC5280 C0DBGYY00281
REGULATOR IC5300 C0DBAYY00755
DC/DC CONVERTER IC5500 C0DBAYY00715
DC/DC CONVERTER IC5501 C0DBAYY00715
REGULATOR IC5603 C0DBFYY00049
REGULATOR IC5604 C0DBGYY00578
REGULATOR & INTERFACEIC6700 C1AB00002948
REGULATOR IC6701 C0DBEYY00123
REGULATOR IC6702 C0DBAYY00462
COMBINED DEMODULATORIC6851 C1AB00003273
LOW VOLTAGE MULTIPLEXEIC6852 C0JBAR000566
LOW VOLTAGE MULTIPLEXEIC6853 C0JBAR000566
LOW VOLTAGE MULTIPLEXEIC6854 C0JBAR000566
REGULATOR IC6855 C0DBAYY00462
REGULATOR IC6856 C0DBAHF00015
REGULATOR IC6857 C0DBFYY00041
IC LDA2 IC8000 MN2WS0110C
CLOCK GENERATOR IC8100 C1ZBZ0003967
DDR SDRAM IC8240 C3ABTY000025
DDR SDRAM IC8241 C3ABTY000025
