Panasonic TX-L42D25B - Page 44

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CAPC9241 F1K1E106A136 25V 10µF
S.M.CAPC9242 F1L1H105A059 50V 1000nF
S.M.CAPC9243 F1K1E106A136 25V 10µF
S.M.CAPC9247 F1H1C105A145 16V 1000nF
S.M.CAPC9248 F1J1E105A231 25V 1µF
S.M.CAPC9249 F1L1H105A059 50V 1000nF
S.M.CAPC9250 F1G1H220A731 50V 22pF
S.M.CAPC9251 F1K1E106A136 25V 10µF
S.M.CAPC9252 F1K1E106A136 25V 10µF
S.M.CAPC9254 F1K1E106A136 25V 10µF
S.M.CAPC9255 F1J1A106A087 10V 10µF
S.M.CAPC9256 F1H1H104A970 50V 100nF
S.M.CAPC9257 F1J1A106A087 10V 10µF
S.M.CAPC9258 F1J1A106A087 10V 10µF
S.M.CAPC9259 F1J1A106A087 10V 10µF
S.M.CAPC9260 F1H1E104A129 25V 100nF
S.M.CAPC9261 F1J1C474A104 16V 470nF
S.M.CAPC9262 F1H1H104A970 50V 100nF
S.M.CAPC9263 F1K1E106A136 25V 10µF
S.M.CAPC9264 F1K1E106A136 25V 10µF
S.M.CAPC9265 F1K1E106A136 25V 10µF
S.M.CAPC9266 F1K1E106A136 25V 10µF
S.M.CAPC9267 F1K1E106A136 25V 10µF
S.M.CAPC9268 F1H1E104A129 25V 100nF
S.M.CAPC9269 F1H1H223A970 50V 22nF
S.M.CAPC9270 F1H1E104A129 25V 100nF
S.M.CAPC9271 F1G1H102A730 50V 1nF
S.M.CAPC9272 F1K1E106A136 25V 10µF
S.M.CAPC9273 F1G1H102A730 50V 1nF
S.M.CAPC9274 F1H1H104A970 50V 100nF
S.M.CAPC9275 F1K1E106A136 25V 10µF
S.M.CAPC9276 F1H1H104A970 50V 100nF
S.M.CAPC9277 F1H1H104A970 50V 100nF
S.M.CAPC9278 F1H1H223A970 50V 22nF
S.M.CAPC9279 F1G1H221A731 50V 220pF
S.M.CAPC9280 F1G1H152A730 50V 1.5nF
S.M.CAPC9283 F1H1H104A970 50V 100nF
S.M.CAPC9284 F1J1E105A231 25V 1µF
S.M.CAPC9285 F1K1E106A136 25V 10µF
S.M.CAPC9286 F1K1E106A136 25V 10µF
S.M.CAPC9287 F1H1H104A970 50V 100nF
S.M.CAPC9288 F1K1E106A136 25V 10µF
S.M.CAPC9289 F1H1H104A970 50V 100nF
S.M.CAPC9290 F1K1E106A136 25V 10µF
S.M.CAPC9291 F1G1H121A731 50V 120pF
S.M.CAPC9292 F1K1H475A210 50V 4700nF
S.M.CAPC9293 F1K1H475A210 50V 4700nF
S.M.CAPC9297 F1G1C104A116 16V 100nF
S.M.CAPC9298 F1K1E106A136 25V 10µF
S.M.CAPC9299 F1J1A106A043 10V 10µF
S.M.CAPC9300 F1H1H104A970 50V 100nF
S.
M.
CAPC9301 F1H1H103A970 50V 10nF
S.M.CAPC9302 F1H1E104A129 25V 100nF
S.M.CAPC9303 F1J1A106A043 10V 10µF
S.M.CAPC9304 F1K1E106A136 25V 10µF
S.M.CAPC9305 F1H1H104A970 50V 100nF
S.M.CAPC9306 F1H1H103A970 50V 10nF
S.M.CAPC9307 F1H1E104A129 25V 100nF
S.M.CAPC9308 F1G1C104A116 16V 100nF
S.M.CAPC9309 F1G1C104A116 16V 100nF
S.M.CAPC9310 F1G1C104A116 16V 100nF
S.M.CAPC9311 F1G1C104A116 16V 100nF
S.M.CAPC9312 F1G1C104A116 16V 100nF
S.M.CAPC9313 F1G1C104A116 16V 100nF
S.M.CAPC9314 F1G1C104A116 16V 100nF
S.M.CAPC9315 F1H1H104A970 50V 100nF
S.M.CAPC9316 F1H1H104A970 50V 100nF
S.M.CAPC9317 F1H1H104A970 50V 100nF
S.M.CAPC9318 F1K1E106A136 25V 10µF
S.M.CAPC9319 F1K1E106A136 25V 10µF
S.M.CAPC9325 F1H1H104A970 50V 100nF
S.M.CAPC9329 F1J1E105A231 25V 1µF
S.M.CAPC9331 F1H1E104A129 25V 100nF
S.M.CAPC9333 F1H1H104A970 50V 100nF
S.M.CAPC9334 F1H1H104A970 50V 100nF
S.M.CAPC9335 F1K1E106A136 25V 10µF
S.M.CAPC9336 F1H1H104A970 50V 100nF
S.M.CAPR5263 F1G1A105A047 10V 1000nF
TERMINALS AND LINKS
PLUG . K4ZZ01000267
T-CON_PANEL FFC WIRE. TSXM104
4P CONNECTOR A02 K1KY04AA0719
A02-K01 WIRE A02-K01 TXJA020QDB
13P CONNECTOR A09 K1KA13BA0270
A09-CN03-TC06 WIREA09-CN03 TXJA090QDB
8P CONNECTOR A10 K1KY08AA0719
A10-V10 WIRE A10-V10 TXJA100QDB
4P CONNECTOR A12 K1KA04BA0055
A12-SPK L/R WIRE A12-SP TXJA120QDB
51P CONNECTOR A15 K1KB51BA0074
13P CONNECTOR A88 K1KY30B00006
XW-XS FFC WIRE A88-XW2 TSXM043
TUNER-TUNER WIRE ATU-XTU TXJTNR0QEB
8P CONNECTOR CN0100 K1KA08AA0714
SD SLOT CN8850 K1NA09E00121
CI SLOT CN8940 K1NA68B00055
OPT TERMINAL D3300 K7AAAY000006
A/V IN_HP TERMINALJK3300 K4AK10B00002
YUV, AUDIO I/O TERMINAJK3301 K2HA7YYA0005
SCART TERMINAL JK3302 K1FY121A0009
SCART TERMINAL JK3303 K1FY121A0009
PC TERMINAL JK3304 K1FY315A0005
HDMI CONNECTOR JK4700 K1FY119D0012
HDMI CONNECTOR JK4701 K1FY119D0012
HDMI CONNECTOR JK4702 K1FY119E0017
HDMI CONNECTOR JK4703 K1FY119D0012
USB TERMINAL JK8700A K1FY104A0013
USB TERMINAL JK8701 K1FY104E0006
ETHERNET TERMINALJK8800 K2LC1YYA0012
60P CONNECTOR TC01 K1MN60BA0126
60P CONNECTOR TC04 K1MN60BA0126
51P CONNECTOR TC05 K1KB51BA0074
LVDS WIRE TC05-A15 K1PY51Y00036
3P CONNECTOR TC06 K1KA03B00242
7P CONNECTOR TC07 K1KA07BA0014
9P CONNECTOR TC08 K1KA09B00112
7P CONNECTOR V10 K1KA07B00135
13P CONNECTOR XW2 K1KY30B00006
DIFFERENCES FOR MODEL TX--L42D25B
EXPLODED VIEW
A P.C.B. 28 A-L42D25B
CABINET ASSY 29 TTY0E0569-1
MODEL LABEL 30 TBM0E2203
INSTRUCTION BOOKS
ENGLISH . TQB0E0929
I.C.s
EEPROM LDA2 IC8950 X24CL42D25B
DIFFERENCES FOR MODEL TX--L42D26B
EXPLODED VIEW
A P.C.B. 28 A-L42D26B
44
