Panasonic TX-L42D25B - Page 82

A-BOARD TNPH0851 - BOTTOM
IC’S
Q2254 3B
IC1100 5C Q2301 5D
IC2950 5A Q3100 3A
IC2952 5A Q3101 3A
IC3000 2B Q3102 3A
IC5500 2E Q3103 3A
IC5501 1E Q4700 4C
IC5603 3C Q4701 4C
IC8100 3D Q4702 4C
IC8300 5B Q4703 5C
IC8302 5A Q4709 4C
IC8400 5E Q4710 4C
Q5055 6D
TRAN’S
Q5240 1C
Q2253 3B
