TX-LR32EM5A
19
8 Measurements and Adjustments
8.1. Voltage chart of A-board
Set A-Board to a dummy set and check the satisfaction with the specified voltage as following table.
8.2. Voltage chart of P-board
Set P-Board to a dummy set and check the satisfaction with the specified voltage as following table.
Note: GND REFERENCE TP7503 (COLD SIDE)
Power Supply Name Measurement Point Specification (V)
SUB1.8V TP8700 1.74 - 1.90
SUB1.2V TP8000 1.14 - 1.26
SUB3.3V TP8701 3.19 - 3.46
SUB5V TP8702 4.9 - 5.1
STB5V TP5400 4.9 - 5.1
PNL12V TP8307 11.5 - 12.5
VOLTAGE TEST POINT
Specification
Operate STBY
5.3V TP7507 5.3 ± 0.10 V 5.3 ± 0.10 V
16.4V TP7508 16.4 ± 0.8 V -
24V TP7509 24V ± 12V -
