Panasonic TX-LR32EM5A - Detailed Electrical Parts List

TX-LR32EM5A
47
13.2.2. Electrical Replacement Parts List
Note: All part will be supplied by PAVCKM.
Safety Ref.
No.
Part No. Part Name & Description Remarks
CAPACITORS
C0085 F1G1C104A077 C 0.1UF 16V
C2002 F1J1H104A717 "C 0.1UF
C2003 F1G1C104A077 C 0.1UF 16V
C2004 F1J1H104A717 "C 0.1UF
C2008 F1JZZ1060001 "C 10UF
C2009 F1G1C104A077 C 0.1UF 16V
C2010 F1G1C1030008 C 0.01UF 16V
C2018 F1J1H104A717 "C 0.1UF
C2105 F1K0J226A049 "C 22UF
C2168 F1G1A105A047 C 1UF 10V
C2169 F1G1A105A047 C 1UF 10V
C2170 F1G1A105A047 C 1UF 10V
C2171 F1G1A105A047 C 1UF 10V
C2172 F1H1A225A051 "C 2.2UF
C2173 F1J1A106A110 "C 10UF
C2174 F1H1A225A051 "C 2.2UF
C2175 F1G1E102A123 C 1000pF 25V
C2176 F1G1E102A123 C 1000pF 25V
C2177 F1G1E102A123 C 1000pF 25V
C2178 F1G1E102A123 C 1000pF 25V
C2754 F1G1H1020008 C 1000PF 50V
C2802 F1G1C1030008 C 0.01UF 16V
C2805 F1H1C104A041 "C 0.1UF
C2811 F1J1A106A087 "C 10UF
C3093 F1G1C1030008 C 0.01UF 16V
C3095 F1G1C1030008 C 0.01UF 16V
C3097 F1G1C1030008 C 0.01UF 16V
C3108 F1G1H100A833 C 10PF 50V
C3109 F1G1H100A833 C 10PF 50V
C3110 F1G1H100A833 C 10PF 50V
C3113 F1G1H470A834 "C 47PF
C3114 F1G1H331A830 "C 330PF
C3121 F1H1C105A145 C 1 uF 16 V
C3125 F1G1A473A079 C 0.047UF 10V
C3130 F1J1A106A087 "C 10UF
C3131 F1J1A106A087 "C 10UF
C3132 F1J1A106A087 "C 10UF
C3133 F1J1A106A087 "C 10UF
C3134 F1J1A106A087 "C 10UF
C3135 F1J1A106A087 "C 10UF
C3136 F1J1A106A087 "C 10UF
C3137 F1J1E105A287 "C 1UF
C3138 F1G1H220A834 "C 22PF
C3139 F1G1H220A834 "C 22PF
C3142 F1G1H331A830 "C 330PF
C3143 F1G1H331A830 "C 330PF
C3169 F1J1A106A110 "C 10UF
C3170 F1J1A106A110 "C 10UF
C3171 F1G1H561A830 C 560 pF 50 V
C3172 F1G1H561A830 C 560 pF 50 V
C3173 F1G1H152A830 "C 1500PF
C3174 F1G1C1030008 C 0.01UF 16V
C3185 F1G1C1030008 C 0.01UF 16V
C3186 F1G1A473A069 "C0.047UF
C3187 F1G1C1030008 C 0.01UF 16V
C3188 F1G1C1030008 C 0.01UF 16V
C3189 F1G1C1030008 C 0.01UF 16V
C3190 F1G1H561A830 C 560 pF 50 V
C3191 F1G1H561A830 C 560 pF 50 V
C3198 F1J1A106A110 "C 10UF
C3199 F1J1A106A110 "C 10UF
C3200 F1G1H1020008 C 1000PF 50V
C3204 F1G1H470A834 "C 47PF
C3205 F1G1H100A833 C 10PF 50V
C3206 F1G1H100A833 C 10PF 50V
C3207 F1G1H100A833 C 10PF 50V
C3208 F1G1H561A830 C 560 pF 50 V
C3209 F1G1H561A830 C 560 pF 50 V
C4085 F1G1C104A077 C 0.1UF 16V
C4548 F1G1A105A047 C 1UF 10V
C4781 F1G1C104A077 C 0.1UF 16V
C4802 F1J1A106A087 "C 10UF
C4804 F1J1A106A087 "C 10UF
C4856 F1H1C105A145 C 1 uF 16 V
C4857 F1H1C105A145 C 1 uF 16 V
C4895 F1G1H470A834 "C 47PF
C4896 F1G1H470A834 "C 47PF
C4898 F1G1H180A834 "C 18PF
C4899 F1G1H180A834 "C 18PF
C4900 F1G1A224A080 C 0.22UF 10V
C4918 F1G1C104A077 C 0.1UF 16V
C4919 F1G1C104A077 C 0.1UF 16V
C4920 F1G1C104A077 C 0.1UF 16V
C4921 F1G1C104A077 C 0.1UF 16V
C4922 F1JZZ1060001 "C 10UF
C4923 F1J1E474A272 "C 0.47UF
C4924 F1J1E474A272 "C 0.47UF
C4925 F1JZZ1060001 "C 10UF
C4926 F1JZZ1060001 "C 10UF
C4927 F1J1E474A272 "C 0.47UF
C4928 F1J1E474A272 "C 0.47UF
C5004 F1G1A105A047 C 1UF 10V
C5006 F1J1E105A287 "C 1UF
C5011 F1G1C104A077 C 0.1UF 16V
C5020 F1H1A474A107 "C 0.47UF
C5021 F1G1A105A047 C 1UF 10V
C5022 F1G1A105A047 C 1UF 10V
C5025 F1JZZ1060001 "C 10UF
C5026 F1H1C105A145 C 1 uF 16 V
C5028 F1JZZ1060001 "C 10UF
C5030 F1JZZ1060001 "C 10UF
C5031 F1JZZ1060001 "C 10UF
C5033 F1JZZ1060001 "C 10UF
C5034 F1JZZ1060001 "C 10UF
C5171 F1G1C1030008 C 0.01UF 16V
C5476 F1G1A105A047 C 1UF 10V
C5477 F1G1A105A047 C 1UF 10V
C5626 EEEHB0J221UP "E 220UF
C5629 F1G1C104A077 C 0.1UF 16V
C5630 F1J1A106A087 "C 10UF
C5631 F1G1C104A077 C 0.1UF 16V
C6000 F1G1H470A834 "C 47PF
C6001 F1G1H470A834 "C 47PF
C6002 F1H1C105A145 C 1 uF 16 V
C6003 F1H1C105A145 C 1 uF 16 V
C6761 F1G1C104A077 C 0.1UF 16V
C6762 F1G1C104A077 C 0.1UF 16V
C6766 F1J1A106A087 "C 10UF
C6767 F1J1A106A087 "C 10UF
C6768 F1J1A106A087 "C 10UF
C6769 F1J1A106A087 "C 10UF
C6770 F1J1A106A087 "C 10UF
C6771 F1J1A106A087 "C 10UF
C6772 F1G1C104A077 C 0.1UF 16V
C6776 F1G1H100A833 C 10PF 50V
C6777 F1G1H100A833 C 10PF 50V
C6778 F1G1H100A833 C 10PF 50V
C6779 F1G1H120A834 "C 12PF
C6780 F1G1H120A834 "C 12PF
C6781 F1G1H220A834 "C 22PF
C7101 F0CAF104A105 C 0.1UF 240V
C7102 F0CAF104A105 C 0.1UF 240V
C7103 F1A2E471A003 "C 470PF
C7104 F1A2E471A003 "C 470PF
