Model No. : TX-LR32EM5A Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
K2CQ2YY00109 AC CORD
1 L0AA07B00008 SPEAKER UNIT
2 L5EDDYY00413 LCD PANEL
3 N2QAYB000803 REMOTE TRANSMITTER
4 TBL3FX00011 PEDESTAL ASSY
TBL5ZX04871 STAND MOUNTING ASSY
TBM4GC9901 MODEL NAME PLATE
TBX5ZA01701 CONTROL BUTTON
TKP5ZA24101 BOTTOM COVER
TKP5ZA24703 SIDE AV BRACKET
5 TKU3FC00501 BACK COVER
TKX5ZA02501 SPEAKER BRACKET
6 TPC3FA00401 PACKING CASE
TPD3FA00071 TOP CUSHION
TPD3FA00081 BOTTOM CUSHION
TPD3FA00091 TOP CENTER CUSHION
TPD3FA00101 BOTTOM CENTER CUSHION
TPE4GH065 SET COVER
TQZ4GB642 FAN BAG ASSY
TSCKF0070001 LVDS CABLE
TXFKK5Z0004 LED PANEL ASSY
TXFKK5Z0006 LED BRACKET ASSY
7 TXFKY5Z0413 CABINET ASSY
XSS4+16FJK SCREW
Electrical Replacement Part List
RTL TXN/K1TQUE K PRINT
RTL TXN/P1RNUA P PRINT
RTL TZT/A1TWUR A PRINT ASSY
