2. Specifications
2.1 WH-SHF09F3E5 WH-UH09FE5
Item Unit Outdoor Unit
Performance Test Condition EN14511
Condition
(Ambient/Water)
A7W35 A2W35
kW 9.00 9.00
BTU/h 30700 30700
Heating Capacity
kcal/h 7740 7740
W/W 4.64 3.45
COP
kcal/hW 3.99 2.97
dB (A) 49 -
Noise Level
Power Level dB 66 -
Air Flow m
3
/min (ft
3
/min) 76.8 (2710)
Refrigeration Control Device Expansion Valve
Refrigeration Oil cm
3
FV50S (1600)
Refrigerant (R407C) kg (oz) 2.90 (102.3)
Height mm (inch) 1340 (52-3/4)
Width mm (inch) 900 (35-7/16)
Dimension
Depth mm (inch) 320 (12-19/32)
Net Weight kg (lbs) 104 (229)
Liquid mm (inch) 9.52 (3/8)
Pipe Diameter
Gas mm (inch) 15.88 (5/8)
Standard Length m (ft) 7 (23.0)
Pipe Length Range m (ft) 3 (9.8) ~ 30 (98.4)
I/D & O/D Height Difference m (ft) 20 (65.6)
Additional Gas Amount g/m (oz/ft) 70 (0.8)
Refrigeration Charge Less m (ft) 10 (32.8)
Type Hermetic Motor (Rotary)
Motor Type Brushless (4-poles)
Compressor
Rated Output kW 3.40
Type Propeller Fan
Material PP
Motor Type DC (8-poles)
Input Power W —
Output Power W 60
Fan
Fan Speed rpm 490 (Top Fan) 530 (Bottom Fan)
Fin material Aluminium (Pre Coat)
Fin Type Corrugated Fin
Row × Stage × FPI 2 × 51 × 18
Heat Exchanger
Size (W × H × L) mm 903.7 × 1295.4 × 38.1
Item Unit
ø Single
V 230
Power Source (Phase, Voltage, Cycle)
Hz 50
Power Supply 1: Phase / Max. Current / Max. Input
Power
ø / A / W Single / 28.5 / 6.09k
Power Supply 2: Phase / Max. Current / Max. Input
Power
ø / A / W Single / 13.0 / 3.00k
Input Power kW 1.94 2.61
Maximum Input Power For Heat Pump System kW 6.09
Starting Current A 9.3
