8
Item Unit
Running Current A 12.9 17.2
Maximum Current For Heat Pump System A 29.0
Power Factor % 91 93
Power factor means total figure of compressor and outdoor fan motor.
Number of core -
Power Cord
Length m (ft) -
Thermostat Electronic Control
Protection Device Electronic Control
Item Unit Indoor Unit
Performance Test Condition EN14511
Outdoor Ambient °C -20 ~ 35
Operation Range
Water Outlet °C 25 ~ 65
Internal Pressure Differential kPa 39.8
dB (A) 33
Noise Level
Power Level dB 46
Height mm (inch) 892 (35-1/8)
Width mm (inch) 502 (19-3/4)
Dimension
Depth mm (inch) 353 (13-29/32)
Net Weight kg (lbs) 47 (104)
Liquid mm (inch) 9.52 (3/8)
Refrigerant Pipe Diameter
Gas mm (inch) 15.88 (5/8)
Inlet mm (inch) 28 (1-3/32)
Water Pipe Diameter
Outlet mm (inch) 28 (1-3/32)
Water Drain Hose Inner Diameter mm (inch) 15.00 (19/32)
Motor Type DC Motor
No. of Speed 7 (Software Selection)
Pump
Input Power W 60
Type Brazed Plate
No. of Plates 80
Size (H × W × L) mm 130 × 93 × 325
Hot Water Coil
Water Flow Rate l/min (m
3
/h) 34.4 (2.1)
Pressure Relief Valve Water Circuit kPa Open: 300, Close: 265 and below
Flow Switch Magnetic Lead Switch
Protection Device A
Residual Current Circuit Breaker / Earth Leakage Circuit Breaker (30)
Volume I 10
Expansion Vessel
MWP bar 3
Capacity of Integrated Electric Heater kW 6.00
Note:
Heating capacities are based on outdoor air temperature of 7°C Dry Bulb (44.6°F Dry Bulb), 6°C Wet Bulb
(42.8°F Wet Bulb) with controlled indoor water inlet temperature of 30°C and water outlet temperature of 35°C.
Specification are subjected to change without prior notice for further improvement.
Flow rate indicated are based on nominal capacity adjustment of leaving water temperature (LWT) 35°C and
∆T
= 5°C.
