11
12
13
14
Auto
Iris
Lens
Connector
Supplies
the
power
and
either.
the
video
signal
or
DC
control
signal
to
the
Auto
Iris
Lens.
The
4-pin
connector
for
the
lens
which
originally
has
different
type
of
connector
is
a
standard
accessory
(Part
No.
YFE4191J100).
Power
Indicator
Gen-lock
Termination
Switch
(G/L
750hms,
ON/OFF)
When
looping
through
the
gen-lock
video
input
signal,
set
this
switch
to
OFF
position
and
all
other
cases,
set
this
to
ON
position.
SYNC
Selection
Switch
(INT,
LL)
This
switch
is
used
to
select
the
camera
synchro-
nization
mode,
INT
:
When
no
signal
is
supplied
to
the
GEN-
LOCK
connector,
the
camera
synchro-
nization
mode
is
set
to
internal
2:1
interlace,
15
Whenever
the
GENLOCK
video
signal
is
supplied
to
the
GENLOCK
connector,
the
camera
synchronization
mode
_
is
automatically
set
to
external
synchro-
nization.
LL:
The
camera
synchronization
mode
is
set
‘to
Line-Lock
even
if
the
GENLOCK
video
signal
is
supplied
to
the
GENLOCK
connector.
Note:
Set
this
switch
to
INT
position
for
gen-lock
operation.
Flange-back
Adjusting
Ring
Used
to
adjust
the
back
focus
or
focus
by
rotating
this
ring
to
clockwise
for
C-mount
lens
or
counterclockwise
for
special
C-mount
(CS
mount)
lens,
CAUTION:
1.
Always
set
this
ring
to
fully
clock-
wise
before
mounting
the
lens.
2.
Do
not
turn
this
ring
too
much
to
counterclockwise
when
the
C-
mount
lens
is
mounted
as
this
could
damage
the
inner
glass
CCD
sensor,
