49
• The following steps of installation and connection work should be done by qualified service person-
nel or system installers and should conform to all local codes.
• Be sure to switch the camera off before installation and connection.
• Do not install the camera near the air outlet of an air conditioner.
INSTALLATION
■ Mounting the Camera
Ceiling mount
The figure shows an example of the camera mounted on a
ceiling with a locally procured bracket.
Refer to the instructions included with the bracket for filling
gaps and holes with waterproof material.
Wall mount
The figure shows an example of the camera mounted on a
wall with the optional WV-Q110E Wall Mount Bracket. See
instructions included with the optional bracket.
Sun Shield
Use the optional WV-7176E Sun Shield to protect the cam-
era from direct sunlight. See instructions included with the
sun shield.
Precautions
To Next Page
