INOXPAN S.L. EN - 33
PHM 950
This microwave is designed to be installed above 850mm from floor level. This microwave cannot
be installed under a worktop or below another oven, in order to avoid liquid spillage.
17. INSTALLATION DIAGRAMS AND DIMENSIONS
NOTE
Respect the ventilation holes in the cabinet, see installation drawings.
available, the product not work properly and
may suffer damage that would NOT be covered by
the warranty.
Push oven completely into the cabinet
and centre it.
Open microwave door and fasten the
appliance to the cabinet using the four
screws provided. Insert the screws
through the front holes.
