Section 1. Printer Overview
SPECIFICATION PTR3E
CONTROLS AND SIGNALS
On-Line Green LED
Power Green LED
Label Red LED
Ribbon Red LED
Error Red LED
LCD Panel 2 Line x 16 Character
On/Off-Line Switch Front Panel
Label Feed Switch Front Panel
Power On/Off Switch Front Panel
POTENTIOMETER ADJUSTMENTS
Print Darkness Front Panel
Pitch Front Panel
Offset Front Panel
Display Front Panel
INTERFACE CONNECTIONS
Parallel* IEEE1284 Compatible Standard
Serial RS232C (9600 to 57600 bps) Standard
RS422/485 (9600 to 57600 bps) Optional
Serial Protocol Hardware Flow Control (Ready/Busy)
Software Flow Control (X-On/X-Off)
Bi-directional Status
Data Transmission ASCII Format
PROCESSING
CPU 32 Bit RISC
Flash ROM 2 MB
SDRAM 16 MB
Receive Buffer 2.95 MB
All specifications subject to change without notice.
* PTR3E comes standard with parallel port. Contact factory if serial port is required.
