1.5.Control Panel
1.5.1.Overview of control panel
The layout of the printer control panel is shown below:
LCD control panel
No. Name Functions
1
LCD Display
Display operation interface and product information.
2
Wi-Fi
indicator/save
toner indicator
Indicate Wi-Fi connection status (applicable to Wi-Fi model only).
Indicate the on/off of save toner function (applicable to non-Wi-Fi
model only).(Please refer to Chapter 1.5.2.1)
3
Toner cartridge/
status indicator
Indicate the status of toner cartridge and printer
(please refer to Chapter 1.5.2.1)
4
Menu
Open the main menu of control panel
5
OK
Confirm the selection on screen
6
UP
Scroll through the menus and options .
For menu items need to input, change the numeric value
by cycleaccumulating.
