7-7
7.4.3. Printing with Optional Tray
7.4.3.1. Installation of Optional Tray
1. Please ensure the correct placement of the printer and the optional trays, as shown below.
2. Plug the power cord into the printer to turn on the power.
Note: • Please cut off the power supply of the printer when install or remove the optional
tray.
• After the installation of the optional tray, please do not lift the printer up during
the printing process, or else, the communication with the optional tray will fail.
Users will need to restart the printer to restore in this case.
3. Open "Printer Properties" on the Device and Printer interface of the operating system,
and click "Secondary Settings", select "Installed" in the "Installable Options" to complete the
installation of the optional tray, as shown in the gure.
To Next Page
