PAR T GOLF DOUBLE EAGLE INSTALLATION AND MAINTENANCE MANUAL
SECTION E ENJOYING YOUR SIMULATOR
E6
Aim Near Camera such that the
Camera Line aligns with Calibration
Point #1
–
Climb the ladder, and while looking upward into the Optisense
locate screw #1 for camera #1.
(Front-to-Back Aiming)
Drawing 10C
–
If you determined that camera line is on the screen side of
Calibration Point #1, slowly turn adjustment screw #1 clockwise.
Turn opposite direction if camera line is on the Tri-Turf side of
Calibration Point #1.
–
Continue turning screw #1 in the same direction, until camera
line aligns with Calibration Point #1. Your indication that the
two are in line is that the display on the screen shows an image
at some arbitrary number and size.
NOTE
: Once camera line #1 is aligned with Calibration Point #1, then camera #1 is aimed front to back.
In the next step, camera #1 will be (i) aimed left to right and fine tuned; front to back.
Properly aim camera #1 left to right
–
Left to right aiming adjustments for the cameras are made by
turning either screw #2 or screw #3.
Drawing 10C
–
Insert allen-wrench / screwdriver tool into either screw #2 or
screw #3, and turn slowly in a clockwise direction.
–
If message numbers go further away from 256, stop and adjust
the other screw in a clockwise direction.
–
Once you have determined which screw to adjust, continue
turning clockwise to bring numbers closer to 256.
NOTE: If the graphical image and the calibration numbers disappears from the screen, it means that the
camera is no longer properly aimed front-to-back. This is easily corrected by turning screw #1 as was
described earlier.
–
Continue alternating adjustments of screw #1 then either (not
both) screw #2 or screw #3 until the message reads
“256”
Congratulations! Camera #1 is now properly aligned. Move the
golf ball onto Calibration Point #2
STEP 5 Aim Camera #2
–
Position ladder on the right side of the Tri-Turf, and away from the
infrared shield, approximately 6 inches from Calibration Point #2. Be
sure the ladder is not in camera's field of vision.
Mark initial location of the
Camera Line
Drawing 10C
–
_
_
With your back toward screen and the golf ball on Calibration Point #2,
place your open hand on the carpet, 12 inches on the screen side of
Calibration Point #2, then slide finger tips slowly toward Calibration
Point #2
When your fingertips cross camera #2’s field of vision, the graphical
representation of an object and the calibration numbers are displayed for
camera #2.
Using a golf tee, mark the general location of the camera line, i.e. the
place camera #2 first sensed your finger.
Aim Camera at Calibration
Point #2
–
Climb the ladder, and while looking upward into the Optisense locate
screw #1 for camera #2.
