PAR T GOLF DOUBLE EAGLE INSTALLATION AND MAINTENANCE MANUAL
SECTION E ENJOYING YOUR SIMULATOR
E7
If you determined that the camera line is on the screen side of
Calibration Point #2, turn adjustment screw #1 counter-clockwise.
Turn opposite direction if it is on the Tri-turf side of Calibration Point
#2.
Continue turning screw #1 in the same direction, until the camera line
aligns with Calibration Point #2. Again, your indication that the placed
object is in the line of sight of the camera is the graphical represention
on the screen.
Aim Middle Camera
left to right
Left to right aiming adjustments for the cameras are made by turning
either screw #2 or screw #3.
Drawing 10C
Insert allen-wrench/screwdriver tool into either Screw #2 or Screw #3,
and turn slowly in a clockwise direction.
If message numbers go further away from 256, stop and adjust the
other screw in a clockwise direction.
Once you have determined which screw to adjust, continue turning
clockwise as numbers approach 256.
NOTE: If the graphical image and the calibration numbers disappears from the screen, it means that the
camera is no longer properly aimed front-to-back. This is easily corrected by turning screw #1 as was
described earlier.
Continue alternating adjustments of screw #1 then either (not both)
screw #2 or screw #3 until the message reads
“ 256”
Congratulations! Camera #2 is now properly aligned.
STEP 6 Aim Camera #3 (Closest to
the screen)
Place a white business card on Calibration Point #3. Position ladder
approximately 2 feet closer to the screen and slightly right of center.
Be sure the ladder is not in the camera's field of vision.
NOTE: Aiming camera #3 requires a slightly different procedure.
Aim Far Camera at
Calibration Point #3
With business card on Calibration Point #3, climb the ladder, and while
looking upward into the Optisense locate screws #1 for camera #3
Slowly turn screw #1 clockwise for up to 5 full turns. If camera #3 has
not detected the business card at Calibration Point #3, then turn Screw
#1 counterclockwise, until it does.
Drawing 10C
_
Now, slowly turn either screw #2 or screw #3, until the message on the
screen read
“256”
Congratulations! The camera #3 is now properly aligned.
