ParaBody 220 - Page 7

7
FIGURE 3
STEP 3:
FIGURE 2
• Insert two WEIGHT PLATE BUSHINGS (23) into each of the fifteen WEIGHT PLATES (22) as shown in FIGURE 2.
STEP 2:
• Slide the WEIGHT PLATE SHAFT (18) thru the hole in the HEAD PLATE (19), and lock in place using one E-RING (60) as shown
in FIGURE 3.
23
22
19
60
18
