Paradox Esprit+ 616 - Basic Operation

2 User’s Manual
1.0 BASIC OPERATION
The Esprit 616, 626, 636 and 646 keypads all
function in the same way, but display the visual
feedback differently.
1.1 VISUAL FEEDBACK
The numbers, symbols, lights and keys on the keypad
communicate the status of your system as described
below.
Figure 1: Overview of the 616 & 626 Keypads
