Paradox IPR512 Getting Started

IPR512: IP Monitoring Receiver 6 of 8 Quick Start
Step 12: Set Security Profile
The receiver supervises the presence of up to 512 assigned Paradox reporting modules. Up to 32 security profiles can be
created per receiver with a programmable polling time (seconds, minutes, or hours). These profiles are then assigned to
each module during registration. The module will send a presence message (~100 bytes) at intervals defined by the
Module Polling Time. If the receiver does not receive at least one presence message from the module within the Receiver
Supervision Time, the receiver can report a communication loss to the Automation Software (see “Step 11: Set Supervision
Loss Report Code” on page 5).
1. From the Main Menu, click Security Profiles.
2. Click the Add button.
3. Type a name for the new security profile.
4. In the Module Polling Time column type a 2-digit value and select a base time from the drop down list. Represents
interval at which the Paradox reporting module will send a presence message.
5. In the Receiver Supervision Time column type a 2-digit value and select base time from the drop down list. This value
must be higher than the Module Polling Time. Represents the time the receiver will wait before reporting a
communication loss.
6. Click Save.
7. The ID column represents the 2-digit value used by the installer when registering a Paradox reporting module to the
receiver.
NOTE: For the Receiver Supervision Time (item #5), we recommend a minimum value of 1 minute. Also, the
Module Polling Time (item #4) must be at least than half the Receiver Supervision Time (e.g., RST: 1 minute - MPT:
30 sec.)
1
2
5
6
43
7
1
2
5
6
43
7
1

Paradox IPR512 Specifications

General

Brand	Paradox
Model	IPR512
Category	Receiver
Language	English
