LED Feedback
The following tables display LED feedback.
ERROR
Problem with the
module
BUS RX
Receiving from panel
BUS TX
Transmitting to panel
RF RX
Receiving wireless
RF TX
Transmitting wireless
R
G
G
G
Y
ERROR
BUS RX
BUS TX
Com fail: GRN/YEL
short / no data
R
ERROR
BUS RX
BUS TX
Com fail: too many
modules / wrong data
R
G
ERROR
BUS RX
BUS TX
Com fail: GRN/
YEL reversed
G
R
G
ERROR
BUS RX
BUS TX
Combus power
too low
R
Legend
R = Red
G = Green
Y = Yellow
= Off
= On
= Flashing
