Overview
This chapter provides an overview of the RTX3 Wireless Expansion Module
(“RTX3”), including the package contents provided with the RTX3, the
system features and an overview of the RTX3 components.
Description
The RTX3 is a 2-way, 32 zone
wireless expansion module which
enables EVO and Spectra SP Series
control panels to support wireless
hardware such as sirens, motion
detectors and remote controls.
Features
• Up to 32 wireless zones
• Support for REM1 / REM2 /
REM3/ REM15 / RAC1 / RAC2
remote controls
• Support for wireless PGMs
• Support for all Magellan
transmitters including 2WPGM
• Support for two RPT1 and eight
K32RF / K37 (SP Series only)
• Support for SR130 / SR150
Wireless Sirens and RPT1
Wireless Repeater (EVO and
SP Series)
• Support for PX8 Output Module
• In-field firmware upgrade
through BabyWare software via
serial or 4-wire connection
• RF jamming supervision
• Low battery, tamper and check-
in supervision
• Transmitter signal strength
display
• 3 PGM outputs and 1 optional
output
• Noise level test and indicator
Included Items
Antenna
Required/Optional Items
• Mounting hardware
• Optional 12Vdc external
power supply (PS17)
Compatibility
• EVO 192 / EVOHD control
panels
• Spectra SP series control
panels
