Parker A4AL-DN - Page 5

Refrigerating Specialties Division
5
Item Description
1 Seal Cap
2 Gasket, Seal Cap
3 Nut, Stuffing Box
4 Packing Ring
5 Packing Washer
6 Adjusting Stem
8 Bonnet
9 Nameplate
10 Screw, Name Plate
11 Screw, Bonnet
12 Spring Rest, Upper
13 Spring, Range
14 Spring Rest, Lower
15 Diaphragm Follower
16 Gasket, Bonnet
17 Diaphragm
18 Seat, Pilot
19 Gasket, Adapter
20 Flg Ring-tube Asm
27 Gauge Port Pipe Plug
28 Adapter, Body
29 Gasket, Body
30 Piston-Stem
31 Screw, Body
32 Body
33 Throttling Plug Asm
34 Spring, Closing
35 Dirt Wiper Retainer
36 Dirt Wiper
37 Seal, Bottom Cap
38 Bottom Cap
39 Screw, Bottom Cap
40 Packing Washer
41 Packing Ring
42 Stuffing Box Nut
43 Gasket, Seal Cap
44 Seal Cap
45 Gasket, Flange
