Refrigerating Specialties Division
10
Repair Kits for A4AO, A4AOE, A4AOS and A4AOSE
20mm (3/4”) 25mm (1”)
Item No. Description Kit No. Qty Kit No. Qty
Flange Bolt Package includes bolts and nuts; no gaskets
50,52-54 Moduplate Kit “MP” 200518 200518
52 Moduplate Only Avail. with Kit 1 Only Avail. with Kit 1
54 O-Ring, “B” Only Avail. with Kit 1 Only Avail. with Kit 1
50 O-Ring, “S”, “D” Only Avail. with Kit 2 Only Avail. with Kit 2
Flange Kit FK-20 FK-25
Specify Flange, Style, FPT, SW, FPT, SW,
Connection, Size WN ODS WN ODS
Kit includes 2 Flanges only Also Also Also Also
Std Avail Std Avail Std Avail Std Avail
3/4 1,1¼ 7/8 1
1/8, 13/8 1 3/4, 1¼ 11/8 13/8, 15/8
Repair Kits for S6A Modular Pressure Pilot Solenoid
S6A Modular Solenoid Pilot
(for A4AOS/A4AOSE)
Port Sizes 20-100mm 3/4” - 4”
Fig. 4
Item Description Qty Kit Number
55 Screw 1 Only Avail. with Kit
58 Coil Assemly 1 See Page 8
67 O-Ring 1 Only Avail. with Kit
68 Knob 1 Only Avail. with Kit
67, 68 Knob Kit 1 205047
69 Lens 1 Only Avail. with Kit
70 Bulb Kit 6 205282
71 O-Ring 1 Only Avail. with Kit
69 , 71 Lens Kit 6 205279
61B Tube Assembly, Solenoid 1 Only Avail. with Kit
61A Nut, Solenoid Tube 1 Only Avail. with Kit
62 Gasket 1 Only Avail. with Kit
61A,61B
62 Tube Kit, Solenoid 1 201036
50 O-Ring 2 Only Avail. with Kit
Also available in
package. See below.
66 Botts 4 Only Avail. with Kit
50,66 Bolt/”O”Ring Kit 1 201574
62 Gasket 1 Only Avail. with Kit
63 Plunger/Needle Assembly 1 Only Avail. with Kit
62,63 Plunger Kit, Needle 1 202019
62 Gasket 1 Only Avail. with Kit
63 Plunger/Needle Assembly 1 Only Avail. with Kit
62,63 Plunger Kit, Needle 1 201021
(D.C. only)
62 Gasket 1 Only Avail. with Kit
63 Plunger/Needle Assembly 1 Only Avail. with Kit
64 SeatAssembly 1 Only Avail. with Kit
