Parker AFL Series User Manual

3
Parker Autoclave Engineers
Instrumentation Products Division
Erie, PA USA
www.autoclave.com | Cat. 02-9309ME
Section 1.0
Introduction
The Parker Autoclave Engineers pump discussed in this manual
is operated using compressed air up to 150 psi (10 bar). Au-
toclave Engineers AFL Series pumps are used for pumping oil,
water and oil/water mixtures. Special seals are also available for
chemical service. Please contact Parker Autoclave Engineers to
discuss availability of special seals. The pump operates using
a pressure ratio of the air piston diameter to the liquid plunger
diameter. Pumps are available in pressure ranges up to 15,500
PSI (1069 bar).
The pump model number coincides with the approximate nomi-
nal ratio of the pump; ex. AFL100-01 is a 113:1 ratio, with an
input air of 100 psi the output pressure would amount to 11,300
PSI (779 bar). (Output pressure = actual ratio x input air pres-
sure). Refer to the product literature for the actual air pressure
ratio.
Section 2.0
Meaning of Safety Words
A safety related message is identied by a safety alert symbol
and a signal word to indicate the level of risk involved with a
particular hazard. The denitions of the three signal words
are as follows:
indicates a potentially hazardous
situation which, if not avoided, could
result in death or serious injury.
indicates a potentially hazardous
situation which, if not avoided, may
result in minor or moderate injury.
Special notes intended to bring attention to procedures
that must be followed to ensure proper installation and
performance will be placed in a box labeled NOTICE.
Section 3.0
Product Specication
See assembly drawing for product specications:
- Pump Geometry
- Pump Materials of Construction
- Maximum Allowable Working Pressure
- Maximum Working Temperature
- Pressure Ratio
- Displacement
- Repair Kit Part Numbers
- Torque Information
- Weights
WARNING
!
CAUTION
!
Section 4.0
Unpacking
The pump has been assembled and pressure tested at Parker
Autoclave Engineers and is ready to be put into service. The
shipping carton should be opened and the contents carefully
examined upon receipt from the carrier. Make sure there is no
obvious damage to the contents. DO NOT use the equipment
if any damage is evident. If damage has occurred, le a claim
with the shipper before contacting Parker Autoclave Engineers
Service Department.
Examine all material within the container and check against the
packing list to be sure all items are accounted for and are not
damaged. Verify that the equipment model number supplied
agrees with what was ordered.
Section 5.0
Tools
At minimum, the tools required for installation of the pump in-
clude a torque wrench, an open end wrench adapter (crows foot
adapter) and an open end adjustable wrench.
Refer to the Tools, Maintenance and Installation Manual provided
with the Data Book for information on torque wrenches and
torque values for Parker Autoclave Engineers tubing and ttings.
Section 6.0
Installation
Please read this manual in its entirety before
attempting to operate a Parker Autoclave Engineers
high pressure liquid pump
!
WARNING
Installation to be performed only by properly
trained individuals.
!
WARNING
Proper protective safety gear must be worn while
installing and operating the pump.
!
WARNING
