Parker Compact EHA - Page 2

2
Instruction Manual
Compact EHA
Bulletin HY22-3200B
Parker Hannifin
Oildyne Division
Contents
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS DESCRIBED HEREIN OR RELATED ITEMS CAN CAUSE
DEATH, PERSONAL INJURY AND PROPERTY DAMAGE.
This document and other information from Parker-Hannin Corporation, its subsidiaries and authorized distributors provide product
or system options for further investigation by users having technical expertise. The user, through its own analysis and testing, is solely
responsible for making the nal selection of the system and components and assuring that all performance, endurance, maintenance,
safety and warning requirements of the application are met. The user must analyze all aspects of the application, follow applicable industry
standards, and follow the information concerning the product in the current product catalog and in any other materials provided from
Parker or its subsidiaries or authorized distributors.
To the extent that Parker or its subsidiaries or authorized distributors provide component or system options based upon data or
specications provided by the user, the user is responsible for determining that such data and specications are suitable and sufcient for
all applications and reasonably foreseeable uses of the components or systems.
Offer of Sale
Please contact your Parker representation for a detailed ’Offer of Sale’.
WARNING – USER RESPONSIBILITY
Table of Contents Page
Introduction 3
Explanation of Warning Labels 3
Description 3
Preparation for Use 3
Installation 5
Start-Up Procedures 6
Special Tools 6
Safe Operating Procedures 6
Operation 6
Maintenance 9
Troubleshooting 9
Declaration of Incorporation 10
➊ Name & address of manufacturer
➋ WARNING - see page 3
➌ WARNING - see page 3
➍ CE Mark
➎ Year of product manufacture
➏ Product type
➐ Part number
➑ Unique identier/serial number
➒ Maximum extend force
➓ Maximum retract force
⓫ Motor voltage
⓬ Motor watts
⓭ Motor horsepower
⓮ Maximum Amperage draw
↑
lbf
)
↓
lbf
)
N(
W
N(
HP
A
New Hope, MN 55428 USA
11
EHA 646608 102345678
A
VDC
Parker Hannifin - Oildyne Division
5520 Hwy 169 North
How to read the label on your EHA:
